How corals can help us make predictions about our future under climate change (cross-posted from ReefBites)

This blog post originally appeared on ReefBites, the student blog of the International Society for Reef Studies.

Every two to seven years, the eastern equatorial Pacific climate oscillates between anomalously warm (El Niño) and cold (La Niña) conditions in a process known as the El Niño Southern Oscillation (ENSO). This process influences sea surface temperatures (SSTs), trade winds, and global teleconnection patterns, which together influence weather conditions all over the world (Collins 2010). Some scientists suggest that extreme El Niño events will happen more often with the warming climate (Federov and Philander 2000; Tudhope 2001; Cai 2014; Liu 2017), which would have profound impacts on communities around the world (for example, by altering patterns of global food production). Other scientists are undecided, pointing to the diversity of historical ENSO patterns, which confounds data that could suggest climate change is causing an impact (Collins 2010; Vecchi and Wittenburg 2010; Emile-Geay 2013, 2016). Fortunately, coral reefs hold a treasure trove of paleoclimate data that could be used to solve the mystery of past ENSO diversity, which would allow scientists to make more accurate predictions about how we can expect climate (and therefore weather) to change in the future.

It isn’t, however, an easy puzzle to solve. Scientists around the world have devoted huge amounts of resources to understanding how ENSO patterns will change as the climate continues to warm, but this has proven difficult because ENSO has historically exhibited differences in amplitude, temporal evolution, and spatial patterns (Capotondi 2015). Disagreements about what differences are caused by climate change and what is natural variation caused by radiative or orbital forcing have led to disagreement about future ENSO patterns. One thing that scientists do agree on, other than the absolute certainty that human-caused climate change is happening, is that in order to understand exactly what variations in ENSO are being influenced by a warming climate, scientists must first identify the background diversity of ENSO patterns, which requires going back potentially thousands of years (Collins 2010; Vecchi and Wittenburg 2010; Cobb 2013). This lack of information has limited the predicting power of climate models, leading to conflicting results.

So how can scientists get to the bottom of this? Instrumental records are limited in their usefulness because they tend to be short and sparse, particularly in remote regions of the Pacific where changes in SST are most pronounced (Emile-Geay 2013). Some proxy records, which are preserved physical characteristics of the environment that can stand in for direct measurements like ice cores and sediment records from lakes (NCDC NOAA, N.D.) may also be limited because they lack the temporal resolution needed to resolve ENSO patterns, which may vary seasonally (Cobb 2013). Luckily for us, coral reefs have been recording changes in the climate for hundreds of years at high resolutions. Similar to tree trunks, as they grow, corals record rings in their skeletons that reveal their age (Figure 1), and because corals are so sensitive to environmental fluctations, the chemistry in each ring can tell scientists about the temperature, rainfall, and water clarity from that year. By drilling into old corals and extracting a long sample (called a core), scientists can reconstruct monthly climate data over several hundred years. Corals therefore provide a hugely valuable source of data that could help us finally unravel the complicated history of ENSO, which in turn would help us accurately predict changes in our future climate.

Figure 1: Each of the light/dark bands in this x-ray of a cross-section of a coral core formed during a year of growth (NASA Earth Observatory 2005).

Stable isotopes, which are elements with the same number of protons but different numbers of neutrons, are a power tool to understanding past climate. The environmental conditions at the time a coral grows its skeleton can influence the number of neutrons an element has. For example, a number of scientists have used stable oxygen isotopes (δ18O and δ16O) to reconstruct the history of sea surface salinity (Figure 2) (e.g. Nurhati 2009). Other scientists have used ratios elements, such as Stronium to Calcium (Sr/Ca) to reconstruct temperature (e.g. Thompson and van Woesik 2009). A clearer picture of climate variability has begun to emerge through the use of these climate proxies from coral cores. We know, for example, that there are two different types of El Niño events, one in which warm water is centered over the central Pacific (known as “CP El Niño”) and one where warm water is over the eastern equatorial Pacific (“EP El Niño”), and that CP El Niño, which is projected to increase with global warming, has happened more frequently in the 21st century than EP El Niño (Wang 2016). But data from across the Pacific are limited, and many of the studies identifying ENSO patterns use proxies from just a few coral cores, highlighting the need for more studies.


Figure 2: Water vapor gradually loses 18O as it travels from the equator to the poles. Because water with heavy 18O isotopes in them condense more easily than normal water molecules, air becomes progressively depleted in 18O as it travels to high latitudes and becomes colder and drier. In turn, the snow that forms most glacial ice is also depleted in 18O. As glacial ice melts, it returns 16O-rich fresh water to the ocean. Therefore, oxygen isotopes preserved in ocean sediments [and coral cores] provide evidence for past ice ages and records of salinity (Riebeek 2005).

Another challenge is deciphering the cores themselves. Recent studies have called into question temperature data derived from coral cores using the common Sr/Ca proxy, because biological processes known as “vital effects” can influence and even override Sr/Ca relationships to temperature in corals during the biomineralization process (Alpert 2016, DeCarlo 2016). As a result, DeCarlo (2016) suggested a new proxy record that can be used to record past SST by combining Sr/Ca and the ratio of Uranium to Calcium (U/Ca) to create a new proxy, which they dubbed “the Sr-U thermometer.”

The need to address climate change only gets more urgent as time passes, which emphasizes how important this research is. Scientists cannot accurately predict the ways that climate change will influence humanity without understanding ENSO diversity. Coral have recorded climate variability in their skeletons for hundreds of years and are therefore a source of high-resolution, long-term data that could prove invaluable if we can only figure out the best way to decipher it. If scientists can understand ENSO’s patterns in the past, we can account for those patterns in climate models, and therefore predict how future ENSO will be influenced by climate change. This would allow us to make clear, accurate predictions about climate change in general, such as how rainfall patterns would impact food production, which could prove critical to the future of humanity.


 Alpert AE, Cohen AL, Oppo DW, DeCarlo TM, Gove JM, Young CW (2016) Comparison of equatorial Pacific sea surface temperature variability and trends with Sr/Ca records from multiple corals. Paleoceanography 31:252-265 (doi: 10.1002/2015PA002897)

Cai W, Borlace S, Lengaigne M, van Rensch P, Collins M, Vecchi G, Timmermann A, Santosa A, McPhaden MJ, Wu L, England MH, Wang G, Guilyardi E, Jin FF (2014) Increasing frequency of extreme El Niño events due to greenhouse warming. Nature Climate Change 4:111-116 (doi: 10.1038/nclimate2100)

Capotondi A, Wittenberg AT, Newman M, Di Lorenzo E, Yu JY, Bracconot P, Cole J, Dewitte B, Giese B, Guilyardi E, Jin FF, Karnauskas K, Kirtman B, Lee T, Schneider N, Xue Y, Yeh SW (2015) Understanding ENSO Diversity. American Meteorological Society 921-938 (doi: 10.1175/BAMS-D-13-00117.1)

Cobb KM, Westphal N, Sayani HR, Watson JT, Di Lorenzo E, CHeng H, Edwards RL, Charles CD (2013) Highly Variable El Niño-Southern Oscillation Throughout the Holocene. Science 339:67-70. (doi: 10.1126/science.1228246)

Collins M, An SI, Cai W, Ganachaud A, Guilyardi E, Jin FF, Jochum M, Lengaigne M, Power S, Timmermann A, Vecchi G, Wittenberg A (2010) The impact of global warming on the tropical Pacific Ocean and El Niño. Nature Geoscience 3:391-397. (doi: 10.1038/ngeo868)

DeCarlo TM, Gaetani GA, Cohen AL, Foster GL, Alpert AE, Stewart JA (2016) Coral Sr-U thermometry. Paleoceanography 3:626-638. (doi: 10.1002/2015PA002908)

Emile-Geay J, Cobb KM, Mann ME, Wittenberg AT (2013) Estimating Central Equatorial Pacific SST Variability over the Past Millennium. Part II: Reconstructions and Implications. Journal of Climate 26:2329-2352. (doi: 10.1175/JCLI-D-11-00511.1)

Emile-Geay J, Cobb KM, Carre M, Braconnot P, Leloup J, Zhou Y, Harrison SP, Correge T, McGregor HV, Collins M, Driscoll R, Elliot M, Schneider B, Tudhope A (2016) Links between tropical Pacific seasonal, interannual and orbital variability during the Holocene. Nature Geoscience 9:168-175. (doi: 10.1038/NGEO2608)

Federov AV, Philander SG (2001) A Stability Analysis of Tropical Ocean-Atmosphere Interactions: Bridging Measurements and Theory for El Niño. Journal of Climate 14:3086-3101. (doi: 10.1175/1520-0442(2001)014<3086:ASAOTO>2.0.CO;2)

Liu Y, Cobb KM, Song H, Li Q, Li CY, Nakatuska T, Zhisheng A, Zhou W, Cai Q, Li J, Leavitt SW, Sun C, Mei R, Shen CC, Chan MH, Sun J, Yan L, Lei Y, Ma Y, Li X, Chen D, Linderholm HW (2017) Recent enhancement of central Pacific El Niño variability relative to last eight centuries. Nature Communications:15386. (doi: 10.1038/ncomms15386)

NASA Earth Observatory (2005) Climate Close-up: Coral Reefs. From Accessed 18 October 2018.

National Climatic Data Center, National Ocean and Atmospheric Administration (N.D.) What Are “Proxy” Data? From, accessed 14 October 2018.

Nurhati IS, Cobb KM, Charles CD, Dunbar RD (2009) Late 20th century warming and freshening in the central tropical Pacific. Geophysical Research Letters 36:L21606. (doi: 10.1029/2009GL040270)

Reibeek H (2005) Paleoclimatology: the Oxygen Balance. NASA Earth Observatory:, accessed 18 October 2018.

Thompson DM, van Woesik R (2009) Corals escape bleaching in regions that recently and historically experienced frequent thermal stress. Proceedings of the Royal Society B 276:2893-2901 (doi: 10.1098/rspb.2009.0591)

Tudhope AW, Chilcott CP, McCulloch MT, Cook ER, Chappell J, Ellam RM, Lea DW, Lough JM, Shimmield GB (2001) Variability in the El Niño-Southern Oscillation Through a Glacial-Interglacial Cycle. Science Magazine 291:1511-1516. (doi: 10.1126/science.1057969)

Vecchi GA, Wittenberg AT (2010) El Niño and our future climate: where do we stand? WIREs Climate Change 1:260-270. (doi: 10.1002/wcc.33)

Wang C, Deser C, Yu JY, DiNezio P, Clement A (2016) El Niño-Southern Oscillation (ENSO): A review. In: Reefs of the Eastern Pacific, Glymn P, Manzello D, and Enochs I, Eds., Springer Science Publisher:85-106. (doi: 10.1007/978-94-017-7499-4_4)
